Electric Hoist with Remote Control, as the name suggests, it's an electric hoist controlled with wireless control.
At present, electric hoist has two control modes: pendant control and remote control. The pendant control is a standard configuration by default, which is to connect the pendant and the electrical control box on the hoist through a control cable. Therefore, when operating hoist running along the beam, the operator also needs to move with it. In contrast, remote control is more convenient. After installing the receiver on the hoist, the operator can control the electric hoist through the transmitter in his hand. The radio control pendant can also be smaller, lighter and more ergonomic. Of course, you can also configure these two control modes for your electric hoist at the same time.
Benefits of Electric Hoist with Remote Control
- Easy to operate
- The operator can control the electric hoist away from the lifting material, which is safer
- There is no control cable, avoiding all kinds of cables cabling
- The remote control is powered by lithium battery, which is safer
Lifting Capacity of Electric Hoist with Remote Control
The lifting capacity of remote control electric hoist is the same with pendant control electric hoist. Capacity of monorail electric hoist with remote control is up to 20 tons, for double girder crab hoist, the lifting capacity is up to 32 tons.
Speed of Electric Hoist with Remote Control
The lifting speed of traditional electric hoist with remote control is 8 m/min, two speed electric hoist speed is 0.8/8 m/min. For European-spec electric hoist, the lifting speed is 0.8/5 m/min. All the hoist traveling speed is up to 20 m/min.
Types of Electric Hoist with Remote Control
Monorail electric hoist with remote control
Electric Wire Rope Hoist with Remote Control
- Widely used in factory, warehouse, stockyard, etc.
- Lifting Capacity: 1~20t
- Lifting Height: 6/9/12/18m (according your needs)
- Voltage: 220-660V 50/60Hz 3Phase
- Working Class: M3, M4
- Ambient Temperature: -25~40℃
Electric Chain Hoist with Remote Control
- Widely used in factory, warehouse, stockyard, etc.
- Lifting Capacity: 1~35t
- Lifting Height: 6/9/12/18m (according your needs)
- Voltage: 220-660V 50/60Hz 3Phase
- Working Class: M3, M4
- Ambient Temperature: -25~40℃
Electric crab hoist with remote control
Traditional Electric Crab Hoist with Remote Control
- Widely used in factory, warehouse, stockyard, etc.
- Lifting Capacity: 1~32t
- Lifting Height: 6/9/12/18m (according your needs)
- Voltage: 220-660V 50/60Hz 3Phase
- Working Class: M3, M4
- Ambient Temperature: -25~40℃
European-spec Electric Crab Hoist with Remote Control
- Widely used on double girder gantry crane, overhead crane
- Lifting Capacity: 1~80t
- Lifting Height: 6/9/12/18m (according your needs)
- Voltage: 220-660V 50/60Hz 3Phase
- Working Class: M5
- Ambient Temperature: -25~40℃
Electric Open Winch Trolley with Remote Control
- Widely used on double girder gantry crane, overhead crane
- Lifting Capacity: 1~500t
- Lifting Height: 6/9/12/18m (according your needs)
- Voltage: 220-660V 50/60Hz 3Phase
- Working Class: M5, M6
- Ambient Temperature: -25~40℃
Why Choose Yuantai Crane Remote Control Electric Hoist
- Tailor-made Hoist and Crane Solutions
- Yuantai Crane is able to supply customized solution according your real working situation. On the premise of meeting the requirements of use, we will save you the cost as much as possible.
- Quality Assurance
- Perfect quality control system, focusing on product quality. Products are the carrier of all services and trust.
- All crane products and components are passed ISO / CE certifications.
- Perfect service makes you worry-free
- Offer crane installation and maintenance service.
- Free crane operation training service for your staff.
- Up to 20 years of accessory support.
How to Get Remote Control Electric Hoist Price?
We are excited for the opportunity to work with you and find the right solution for your problem, no matter how complex or unique. We'll work with you from the very beginning of your project to the very end while we continue to provide you with support after it is finished. For getting the industrial electric hoist solution that meets your working conditions, please send us a detailed request as follow:
- Lifting capacity:
- Lifting height:
- Power supply (e.g., 380V 50Hz 3Phase):
- Detailed working conditions of the crane:
- How many hours does your crane need to work per day?
- Other requirements:
